CDA Appliances

Zone Information

• Number of zones: 4 plus 1 bridging zone
• Front left: 210mm, 2kW or 3kW with booster
• Front right: 180mm, 1.6kW or 2.5kW with booster
• Rear left: 160mm, 1.4kW or 2.1kW with booster
• Rear right: 180mm, 1.6kW or 2.5kW with booster

Misc Information

• WEEE Category: 1

Technical Specification

• Rated power: 7.4 kW
• Power supply: 32 A

Zone Information

• Front left: 210mm: 2kW, 2.8kW with booster
• Front right: 180mm: 1.5kW, 2.5kW with booster
• Rear left: 160mm: 1.2kW, 1.4kW with booster
• Rear right: 180mm: 1.5kW, 2.5kW with booster

Misc Information

• WEEE Category: 01

Technical Specification

• Mains cable: 130cm

Zone Information

• Front left zone type: 210mm, 2kW or 3kW with booster
• Front right zone type: 160mm, 1.4kW or 2.1kW with booster
• Rear left zone type: 160mm, 1.4kW or 2.1kW with booster
• Rear right zone type: 210mm, 2kW or 3kW with booster

Misc Information

• WEEE Category: 1

Zone Information

• Front left: 210mm, 2kW or 2.8kW with booster
• Front right: 160mm, 1.4kW or 2.1kW with booster
• Rear left: 160mm, 1.4kW or 2.1kW with booster
• Rear right: 210mm, 2kW or 2.8kW with booster

Misc Information

• WEEE Category: 1

Technical Specification

• Power cable length: 1.5000 m
• Power cable size: 4
• Power cable type: H05VV-F
• Power supply: 13 A
• Rated electrical power: 2.8000 kW

Zone Information

• Front left: 160mm: 1.4kW
• Rear left: 160mm: 1.4kW

Misc Information

• WEEE Category: 01

Accessories

• LPG conversion kit included
• Wok support

Technical Specification

• Rated electrical power: 2.0000 W
• Power supply: 3 A
• Rated gas input: 11.3000 kW
• Mains cable: H05VV-F

Burners

• Front left, semi-rapid: 1.75 kW
• Front right, auxiliary: 1 kW
• Centre, triple ring/wok: 3.8 kW
• Rear left, semi-rapid: 1.75 kW
• Rear right, rapid: 3 kW

Misc Information

• WEEE Category: 1

Accessories

• LPG conversion kit included
• Wok support

Technical Specification

• Rated electrical power: 1.1000 W
• Power supply: 3 A
• Rated gas input: 8.3000 kW
• Mains cable: H05VV-F

Burners

• Front left, triple ring/wok: 3.8 kW
• Front right, auxiliary: 1 kW
• Rear left, semi-rapid: 1.75 kW
• Rear right, semi-rapid: 1.75 kW

Misc Information

• WEEE Category: 1

Accessories

• LPG conversion kit included

Technical Specification

• Rated electrical power: 1.1000 W
• Power supply: 3 A
• Rated gas input: 8.3000 kW
• Mains cable: H05VV-F

Burners

• Front left, triple ring/wok: 3.8 kW
• Front right, auxiliary: 1 kW
• Rear left, semi-rapid: 1.75 kW
• Rear right, semi-rapid: 1.75 kW

Misc Information

• WEEE Category: 1

Accessories

• LPG conversion kit included

Technical Specification

• Rated electrical power: 1.1000 W
• Power supply: 3 A
• Rated gas input: 8.3000 kW
• Mains cable: H05VV-F

Burners

• Front left, triple ring/wok: 3.8 kW
• Front right, auxiliary: 1 kW
• Rear left, semi-rapid: 1.75 kW
• Rear right, semi-rapid: 1.75 kW

Misc Information

• WEEE Category: 1

Accessories

• LPG conversion kit included

Technical Specification

• Rated electrical power: 1.1000 W
• Power supply: 3 A
• Rated gas input: 7.5000 kW
• Mains cable: H05VV-F

Burners

• Front left, rapid: 3 kW
• Front right, auxiliary: 1 kW
• Rear left, semi-rapid: 1.75 kW
• Rear right, semi-rapid: 1.75 kW

Misc Information

• WEEE Category: 1

Technical Specification

• Rated electrical power: 6.5000 kW
• Power supply required: 30 A
• Power cable length: 1.5000 m
• Power cable type: H05VV-F
• Mains cable: Yes

Zone Information

• Front left: 210mm: 2.3kW
• Front right: 145mm: 1.2kW
• Rear left: 145mm: 1.2kW
• Rear right: 180mm: 1.8kW

Misc Information

• WEEE Category: 01

Technical Specification

• Rated electrical power: 6.0000 kW
• Power supply required: 30 A
• Power cable length: 1.5000 m
• Power cable type: H05VV-F

Zone Information

• Front left: 180mm: 1.8kW
• Front right: 145mm: 1.2kW
• Rear left: 145mm: 1.2kW
• Rear right: 180mm: 1.8kW

Misc Information

• WEEE Category: 1

Technical Specification

• Required height over gas hobs: 550 mm (min)
• Required height over electric hobs: 550 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Pressure value: 0 Pa
• Outlet diameter: 120-125mm mm

Extraction Rates And Noise

• Noise level: 64 dBA
• Extraction rate: 350 m3/hr
• Extraction rate at first speed: 186 m³/hr
• Extraction rate at second speed: 276 m³/hr
• Extraction rate at third speed: 350 m³/hr
• Noise level at first speed: 54 dBA
• Noise level at second speed: 60 dBA
• Noise level at third speed: 64 dBA

Filters

• Charcoal filter code: CHA15
• Aluminium grease filter
• Number of charcoal filters (optional): 1
• Ducting kit: AED51/53/54

Misc Information

• WEEE Category: 01

Technical Specification

• Required height over gas hobs: 550 mm (min)
• Required height over electric hobs: 550 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Pressure value: 0 Pa
• Outlet diameter: 120-125mm mm

Extraction Rates And Noise

• Noise level: 64 dBA
• Extraction rate: 350 m3/hr
• Extraction rate at first speed: 186 m³/hr
• Extraction rate at second speed: 276 m³/hr
• Extraction rate at third speed: 350 m³/hr
• Noise level at first speed: 54 dBA
• Noise level at second speed: 60 dBA
• Noise level at third speed: 64 dBA

Filters

• Charcoal filter code: CHA15
• Aluminium grease filter
• Number of charcoal filters (optional): 1
• Ducting kit: AED51/53/54

Misc Information

• WEEE Category: 01

Technical Specification

• Required height over gas hobs: 550 mm (min)
• Required height over electric hobs: 550 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Pressure value: 0 Pa
• Outlet diameter: 120-125mm mm

Extraction Rates And Noise

• Noise level at first speed: 54 dBA
• Extraction rate at third speed: 350 m3/hr
• Noise level at second speed: 60 dBA
• Extraction rate at first speed: 186 m³/hr
• Extraction rate at second speed: 276 m³/hr
• Noise level at third speed: 64 dBA

Filters

• Charcoal filter code: CHA15
• Aluminium grease filter
• Number of charcoal filters (optional): 1
• Ducting kit: AED51/53/54

Misc Information

• WEEE Category: 01

Technical Specification

• Mains lead length: 1.5 m
• Rated electrical power: 164 W
• Required height over gas hobs: 650 mm (min)
• Required height over electric hobs: 450 mm (min)
• Outlet diameter: 150 mm

Extraction Rates And Noise

• Extraction rate at fourth speed: 730 m3/hr
• Noise level at fourth speed: 68 dBA
• Extraction rate at first speed: 290 m³/hr
• Extraction rate at second speed: 390 m³/hr
• Extraction rate at third speed: 500 m³/hr
• Noise level at first speed: 48 dBA
• Noise level at second speed: 55 dBA
• Noise level at third speed: 59 dBA

Energy

• Energy rating: A+++
• Annual energy consumption: 25.0000 kWh

Lighting

• Lighting: LED

Filters

• Charcoal filter code: CHA42

Misc Information

• WEEE Category: 1

Optional Accessories

• Ducting kit code: AED 51/53/54
• Charcoal filter for re-circulation : CHA15 (pack of 1)
• Aluminium grease filter: GRE3M

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Outlet diameter: 120mm mm

Lighting

• Type of light: LED
• Wattage of lights: 4W

Filters

• Number of charcoal filters (optional): 1
• Charcoal filter code: CHA15
• Ducting kit: AED510/560

Misc Information

• WEEE Category: 01

Optional Accessories

• Ducting kit code: AED 51/53/54
• Charcoal filter for re-circulation : CHA15 (pack of 1)

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Outlet diameter: 120mm mm

Energy

• Energy rating: B

Lighting

• Type of light: LED
• Wattage of lights: 4W

Filters

• Number of grease filters: 1
• Number of charcoal filters (optional): 1
• Charcoal filter code: CHA15
• Ducting kit: AED510/560

Misc Information

• WEEE Category: 01

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Mains lead rating: H05VV-F m
• Protection class: Class I
• Outlet diameter: 120mm/150mm mm
• Outlet diameter: It is best to use the AED6 (150mm) ducting kit rather than the AED5 (120mm) with the adaptor. This keeps noise levels to a minimum. mm

Extraction Rates And Noise

• Noise level: 61 dBA
• Extraction rate: 377 m3/hr
• Extraction rate at first speed: 224 m³/hr
• Extraction rate at second speed: 315 m³/hr
• Extraction rate at third speed: 377 m³/hr
• Noise level at first speed: 51 dBA
• Noise level at second speed: 58 dBA
• Noise level at third speed: 61 dBA

Filters

• Charcoal filters: CHA12 (pack of 1)
• Number of layers: 4
• Number of grease filters: 1
• Number of charcoal filters (optional): 1
• Ducting kit: AED61/63/64 or AED51/53/54 with adaptor

Fitting Notes

• Fitting note: please ensure that you check the ceiling height is sufficient to allow the required clearance between the hob and extractor

Misc Information

• WEEE Category: 01

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Mains lead rating: H05VV-F m
• Protection class: Class I
• Outlet diameter: 120mm/150mm mm
• Outlet diameter: It is best to use the AED6 (150mm) ducting kit rather than the AED5 (120mm) with the adaptor. This keeps noise levels to a minimum. mm

Extraction Rates And Noise

• Noise level: 60 dBA
• Extraction rate: 391 m3/hr
• Extraction rate at first speed: 218 m³/hr
• Extraction rate at second speed: 302 m³/hr
• Extraction rate at third speed: 391 m³/hr
• Noise level at first speed: 50 dBA
• Noise level at second speed: 58 dBA
• Noise level at third speed: 60 dBA

Filters

• Charcoal filters: CHA12 (pack of 1)
• Number of layers: 4
• Number of grease filters: 1
• Number of charcoal filters (optional): 1
• Ducting kit: AED61/63/64 or AED51/53/54 with adaptor

Fitting Notes

• Fitting note: please ensure that you check the ceiling height is sufficient to allow the required clearnace between the hob and extractor

Misc Information

• WEEE Category: 01

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Mains lead rating: H05VV-F m
• Protection class: Class I
• Outlet diameter: 120mm/150mm mm
• Outlet diameter: It is best to use the AED6 (150mm) ducting kit rather than the AED5 (120mm) with the adaptor. This keeps noise levels to a minimum. mm

Extraction Rates And Noise

• Extraction rate: 391 m3/hr
• Noise level: 60 dBA
• Extraction rate at first speed: 218 m³/hr
• Extraction rate at second speed: 302 m³/hr
• Extraction rate at third speed: 391 m³/hr
• Noise level at first speed: 50 dBA
• Noise level at second speed: 58 dBA
• Noise level at third speed: 60 dBA

Filters

• Charcoal filters: CHA12 (pack of 1)
• Number of layers: 4
• Number of grease filters: 1
• Number of charcoal filters (optional): 1
• Ducting kit: AED61/63/64 or AED51/53/54 with adaptor

Fitting Notes

• Fitting note: please ensure that you check the ceiling height is sufficient to allow the required clearance between the hob and extractor

Misc Information

• WEEE Category: 01

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Mains lead rating: H05VV-F m
• Protection class: Class I
• Outlet diameter: 120mm/150mm mm
• Outlet diameter: It is best to use the AED6 (150mm) ducting kit rather than the AED5 (120mm) with the adaptor. This keeps noise levels to a minimum. mm

Extraction Rates And Noise

• Extraction rate: 391 m3/hr
• Noise level: 60 dBA
• Extraction rate at first speed: 218 m³/hr
• Extraction rate at second speed: 302 m³/hr
• Extraction rate at third speed: 391 m³/hr
• Noise level at first speed: 50 dBA
• Noise level at second speed: 58 dBA
• Noise level at third speed: 60 dBA

Filters

• Charcoal filters: CHA12 (pack of 1)
• Number of layers: 4
• Number of grease filters: 1
• Number of charcoal filters (optional): 1
• Ducting kit: AED61/63/64 or AED51/53/54 with adaptor

Fitting Notes

• Fitting note: please ensure that you check the ceiling height is sufficient to allow the required clearnace between the hob and extractor

Misc Information

• WEEE Category: 01

Optional Accessories

• Ducting kit code: 120mm, AED 510/560
• Ducting kit code: 150mm, AED 610/660

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Power supply: 3 A
• Mains lead length: 1 m
• Mains lead rating: H05VV-F m
• Protection class: Class I
• Outlet diameter: 120mm/150mm mm
• Outlet diameter: It is best to use the AED6 (150mm) ducting kit rather than the AED5 (120mm) with the adaptor. This keeps noise levels to a minimum. mm

Extraction Rates And Noise

• Extraction rate: 391 m3/hr
• Noise level: 60 dBA
• Extraction rate at first speed: 218 m³/hr
• Extraction rate at second speed: 302 m³/hr
• Extraction rate at third speed: 391 m³/hr
• Noise level at first speed: 50 dBA
• Noise level at second speed: 58 dBA
• Noise level at third speed: 60 dBA

Filters

• Charcoal filters: CHA12 (pack of 1)
• Number of layers: 4
• Number of grease filters: 1
• Number of charcoal filters (optional): 1
• Ducting kit: AED610/660 or AED510/560ith adaptor

Fitting Notes

• Fitting note: please ensure that you check the ceiling height is sufficient to allow the required clearance between the hob and extractor

Misc Information

• WEEE Category: 01

Technical Specification

• Required height over gas hobs: 700 mm (min)
• Required height over electric hobs: 600 mm (min)
• Mains lead length: 1 m
• Outlet diameter: 150mm

Extraction Rates And Noise

• Extraction rate at first speed: 305 m3/hr
• Noise level at first speed: 51 dBA
• Extraction rate at second speed: 415 m3/hr
• Noise level at second speed: 60 dBA
• Extraction rate at third speed: 614 m3/hr
• Noise level at third speed: 65 dBA

Energy

• Energy rating: A++

Lighting

• Lighting: 2 x 1W
• Type of light: LED

Filters

• Aluminium grease filter
• Charcoal filter code: CHA12

Misc Information

• WEEE Category: 1
